2025 Greyhawk XL | 32U

2025 Greyhawk XL

See Floorplan with
an Option Added:

32U 15 cu.ft. 12V Refrigerator Power Theater Seating

See Floorplan with an Option Added:

Interior Design

Stillwater

Stillwater

Exterior

Partial Paint Package

Partial Paint Package

Build and Price Your Jayco

Choose your customizations below and receive a price estimate.

Specifications

Weights
Gross Vehicle Weight Rating (lbs)19,500
Gross Combined Weight Rating (lbs)31,500
Measurements
Exterior Length (overall)34' 2"
Exterior Height (with A/C)12' 0"
Exterior Width8' 5"
Exterior Width (with slides out)11' 3"
Interior Height (main)7' 0"
Awning Length20' 0"
Tank Capacities
Fresh Water Capacity (gals)42.5
Gray Water Capacity (gals)31.0
Black Tank Capacity (gals)31.0
Propane Unit (lbs)24
Fuel Tank Capacity (gals)67
Miscellaneous
Sleepsup to 5
# of outside storage compartments7
Tire Size19.5 x 6.75 Aluminum
Engine Size6.7L Power Stroke V8 Turbo Diesel
Exterior Cargo Capacity (cu. ft.)58
Exteriors
Partial Paint Package $0
Interior Designs
Stillwater $0
Options
Customer Value Package (Mandatory) $25,493
Power theater seating $2,093
LED HD Smart TV in bedroom $413
15 cu. ft. 12V refrigerator $743
Dual A/C units (15,000 and 13,500 BTU) with power management system $1,193
Aluminum rims $2,993
Folding windshield sun shade $488
Canadian Standards $293

$266,550 MSRP*

*MSRP shown in USD. Doesn’t include freight and dealer prep charges

Build and Price »
Greyhawk XL

2025 Greyhawk XL

Starting at $266,550

Go where others can’t in the Jayco Greyhawk XL Super Class C. This motorhome offers a combination of luxury and capability, perfect for your adventures.

Built on the Ford® F-550 with a 6.7L Power Stroke V8 Turbo diesel engine, the Greyhawk XL is designed for reliability and performance. Its one-piece fiberglass front cap with an automotive-bonded panoramic window eliminates seams found on competitors' caps, a notorious leak point on a Class C motorhome. At the campground, level quicker and start enjoying your time sooner thanks to automatic hydraulic leveling jacks. These jacks allow for less set-up time by automatically leveling the coach with the touch of a button. Be the envy of the campground with Greyhawk XL’s stunning partial paint package and frameless windows, which give a clean, automotive look while protecting the window seals for longevity. The Greyhawk XL's durable fiberglass roof ensures you don’t have to worry about catching a low-hanging branch; a common worry for those with rubber roofs.

Inside the Greyhawk XL, enjoy a consistently comfortable climate with the 15,000 BTU ducted A/C with heat pump and the 30,000 BTU auto-ignition furnace. The 10-gallon gas/electric DSI auto-ignition water heater is more reliable than tankless heaters and replenishes three times per hour, providing consistently hot water for long showers. The Greyhawk XL is also equipped with an Onan® 6,000W generator with auto-gen start and a 2,000W inverter to provide power during your travels. The 200W solar panel with dual controller and second house battery support your off-grid adventures. Enjoy the convenience and safety of modern features, including a Ford® SYNC® 4 infotainment center with Apple CarPlay® and Android Auto™, backup and side-view cameras and heated, remote-controlled, chrome side-view mirrors. The Firefly total coach control system with wall-mounted touchscreen and mobile app integration provides remote access to control your coach’s functions, ensuring your travels are as smooth and enjoyable as possible.

Standard Features
and Options

JRide<sup>®</sup>
Stronghold VBL™ Lamination
Solar Power
One-Piece Seamless Front Cap
Incredible Bunk Ratings
Seatbelts in All Designated Seating Locations

JRide®

We engineer each motorhome with several specific enhancements for a powerful blend of precise handling and renowned stability on the road. Because the journey should be as exciting as the destination.

Learn more »

Stronghold VBL™ Lamination

Every sidewall, rear wall and slide room wall is bonded together for a minimum of 16 minutes under 144 tons of pressure to create the lightest, yet strongest, construction available in the RV industry.

Learn more »

Solar Power

Jayco is one of the first companies to offer solar prep, or solar panels, on every single motorhome.  With sidewall or roof-mounted prep kits, you have the option to easily install solar panels, or additional panels if already solar equipped, for extra power at your camp.

Learn more »

One-Piece Seamless Front Cap

An RVs front cap bears a lot of the brunt of the road. The one-piece, seamless front cap resists wear and tear like fading or moisture damage over the years.

Learn more »

Incredible Bunk Ratings

Go ahead and bring another traveler or some extra gear. With an overhead bunk capacity of 750 lbs., Jayco beats the industry standard by 300lbs. On top of that, Jayco offers a 300 lb. capacity in each standard bunk.

Learn more »

Seatbelts in All Designated Seating Locations

To help you keep you most precious cargo safe as you roll on down the road, we install seatbelts in every designated seating location.

Learn more »
