2027 North Point Floorplans

Standard Exterior Equipment

• 102 in. wide-body construction
• 12 in. structural steel I-beam frame with 8 in. or 10 in. Monster Beam™ steel drop-frame construction
• Battery disconnect switch
• Built-in sewer hose carrier
• Climate Shield™ zero-degree-tested weather protection package:
  • 40,000 BTU furnace
  • Double-layer fiberglass batt insulation in roof and floor
  • Fully enclosed and heated underbelly with ducted heat
  • 2 in. block foam insulation with reflective foil barrier
• Digital TV antenna
• Frameless, dark-tinted safety-glass windows
• Fully enclosed universal docking center featuring:
  • Black tank flush system
  • Quick-connect outside shower
  • Selectable water connections
  • Winterization and sanitation hookups
• Inverter pre-wire to select outlets
• JayPort® outside griddle prep system (all floorplans without a standard outside kitchen)
• JaySMART™ LED lighting system (Safety Markers And Reverse Travel) (patented)
• Magnum Truss™ XL6™ roof system with Alpha Systems® roofing membrane and limited lifetime warranty
• Painted fiberglass front cap with double clear coat finish and integrated specialty LED lighting
• Pass-through storage with Slam Latch™ baggage doors
• Skirt-metal enclosed drop frame
• Stronghold VBL™ aluminum-framed, vacuum-bond laminated gel-coated fiberglass exterior walls, including rear wall and slide room end walls
• Under-mounted spare tire

Standard Interior Equipment

• 5/8 in. tongue-and-groove joined plywood floor decking
• Carbon monoxide and LP detector
• Ceiling fan (select models)
• CPAP prepped bedroom with folding shelf
• Dual USB charging ports throughout
• Flip-up countertop extension (select models)
• Sliding hidden storage in bedroom chest of drawers (select models)
• Flip-up tabletop storage next to tri-fold sofa (select models)
• Gas-strutted under-bed storage
• Handcrafted hardwood doors and drawers
• Integrated under-mount sink and lever faucet in main bathroom
• LED accent lighting above slideouts
• LED backlit custom framed mirror and medicine cabinet (select models)
• No in-floor heat registers throughout coach
• Pull-out cutting board above trash can
• Residential bedspread
• “Shoe garage” in hallway step (select models)
• Soft close, heavy-duty, 75 lb. full-extension, steel ball-bearing drawer guides
• Solid hardwood slide fascia
• Stain protected fabric on all furniture
• Toekick nightlights in bedroom and bathroom
• Tri-fold hide-a-bed sofa with residential sleep surface (select models)
• Up/down switch to raise/lower the TV by theater seats
• Vinyl flooring (made in the USA) throughout (including slideout floors)

Customer Value Package (Mandatory)

• 15K BTU “Whisper Quiet” A/C (main) / 15K BTU “Whisper Quiet” A/C (bedroom)
• On-demand tankless hot water heater
• 4K Smart LED HDTV with fully digital HDMI® output and two extra HDMI cables
• Backup, main entrance door, and side observation security camera prep (includes a power switch in the bedroom to use the monitor for security)
• Custom, black, machined aluminum rims
• Electric patio awning
• Hidden hinges, magnet latches
• JBL® home entertainment system with sound bar and wireless subwoofer
• Keyed-Alike™ lock system (single key for all doors/locks)
• Residential king (72 x 80 in.) mattress with under-bed storage
• Residential dovetail-jointed drawers throughout
• (2) 30 lb. propane bottles with auto regulator
• Overlander I Solar Package

Customer Value Package (Optional)

• with 15,000 BTU A/C and Heat Pump

5 Star Handling Package (Mandatory)

• Dexter® axles with Nev-R-Adjust® brakes and E-Z Lube® hubs
• MORryde® CRE3000™ rubberized suspension system
• Rota-flex® pin box
• Wet-bolt fasteners with bronze bushings
• 4,000 lb. leaf springs
• 17.5 in. 16-ply tires

Luxury Package (Mandatory)

• 2nd electric patio awning
• 6-point hydraulic auto-leveling system
• Frameless dark-tinted safety-glass windows
• Free-standing roll-top table (no pedestal) with two freestanding chairs and two folding chairs
• 12V refrigerator with 1,800W inverter
• 30 in. space-saving microwave
• 21 in. range
• High-gloss gel-coated sidewalls
• LED fireplace with electric space heater
• MORryde® StepAbove™ entrance steps (main entrance)
• Oversized multi-battery compartment
• Privacy night roller shades in living room
• Residential solid-surface kitchen countertops
• Residential walk-in shower with seat prep
• Washer/dryer prep
• Residential NuvoH2O® whole-coach water system with water softening and three replacement cartridges
• Residential “Do-It-All” kitchen sink

Extreme Weather Package (Optional)

• 120V heat pads for holding and freshwater tanks
• 12V electric water line wrap
• Interior illuminated switch

Options

• 3rd living area A/C (15,000 BTU)
• Overlander II Solar Package
• Generator prep
• 7,000W Onan® dual-fuel generator (includes generator prep)
• Dual-pane tinted safety-glass windows
• Slideout awnings (3) (310RLTS, 375TBDB, 391TBBH, 365RKTS)
• Slideout awnings (4) (381CKRE, 361RLBH, 395DSDB)
• Outside HALO® griddle for JayPort® system (N/A on 375TBDB, 391TBBH)
• Theater seating with roll-top dinette (375TBDB)
• Queen residential foam-top mattress
