2027 Pinnacle Floorplans

Standard Exterior Equipment

• 102 in. wide-body construction
• 12 in. structural steel I-beam frame with 8 in. or 10 in. Monster Beam™ steel drop-frame construction
• 120V heat blankets on all holding tanks plus 12V heat tape on fresh water line
• 3,000 lb. rear tow hitch with 4-way pin connector
• Battery disconnect switch
• Built-in sewer hose carrier
• Climate Shield™ zero-degree-tested weather protection package:
  • 40,000 BTU furnace
  • Double-layer fiberglass batt insulation in roof and floor
  • Fully enclosed and heated underbelly with ducted heat
  • 2 in. block foam insulation with reflective foil barrier
• Digital TV antenna
• Exterior marine-grade speakers with Bluetooth® controller
• Frameless dark-tinted safety-glass windows
• Fully enclosed universal docking center featuring:
  • Black tank flush system
  • Quick-connect outside shower
  • Selectable water connections
  • Winterization and sanitation hookups
• Inverter pre-wire to select outlets
• JayPort® outside griddle prep system (standard on all floorplans without a factory-installed outside kitchen)
• JaySMART™ LED lighting system (Safety Markers And Reverse Travel) (patented)
• Magnum Truss™ XL6™ roof system with Alpha Systems® roof membrane
• Painted fiberglass front and rear caps with clear coat finish and integrated specialty LED lighting
• Pass-through storage with Slam Latch™ baggage doors
• Skirt-metal enclosed drop frame
• Stronghold VBL™ aluminum-framed, vacuum-bond laminated gel-coated fiberglass exterior walls, including slide room end walls
• Under-mounted spare tire
• Water manifold system with individual shut-off valves
• Exterior light at termination valves

Standard Interior Equipment

• 12V charging station
• 5/8 in. tongue-and-groove plywood floor decking and 3/8 in. plywood roof decking
• Bathroom skylight
• Built-in laundry hamper in wardrobe (select models)
• Carbon monoxide and LP gas detector
• Cedar-lined front wardrobe closet
• Ceiling fan (select models)
• CPAP-prepped bedroom with flip-up shelf
• Flip-up countertop extension / bar top (select models)
• Hidden sliding storage in bedroom chest of drawers (select models)
• Flip-up tabletop storage next to tri-fold sofa (select models)
• JBL® flush-mount speakers with integrated nightlight above headboard and Bluetooth® controller
• Dishwasher (under kitchen sink installation)
• Pull-out cutting board above trash receptacle
• Gas-strutted under-bed storage
• Handcrafted hardwood doors, stiles, drawers, and trim with hand-painted 90° poly sheen finish
• Integrated under-mount sink with residential-style lever faucet in main bathroom
• LED accent lighting above slideouts
• LED-backlit custom-framed mirror and medicine cabinet (most models)
• No in-floor heat ducts throughout coach
• Pantry with adjustable shelves (most models)
• Porcelain toilet with foot flush
• Residential “Do-It-All” kitchen sink with pull-out faucet, glass rinse, and vegetable rinse features
• Residential dovetail-jointed drawers throughout
• Residential quilted bedspread and pillows
• “Shoe garage” storage in hallway step (select models)
• Soft-close, heavy-duty, 75 lb. full-extension steel ball-bearing drawer guides
• Solid hardwood slideout fascia
• Stain-resistant fabric on all furniture
• Toe-kick nightlights in bedroom, bathroom, and kitchen
• Tri-fold hide-a-bed sofa with residential sleep surface (select models)
• Residential vinyl flooring (Made in the USA) throughout, including slide rooms

Customer Value Package (Mandatory)

• 15,000 BTU “Whisper Quiet” bedroom A/C
• 15,000 BTU “Whisper Quiet” main A/C with heat pump
• On-demand tankless water heater
• 4K Smart LED HDTV with fully digital HDMI® output and two additional HDMI® cables
• Backup, main entry door, and side-view observation camera prep, including bedroom power switch for optional security monitor
• Electric patio awning
• Hidden hinges, magnetic latches, and soft-close cabinet doors
• JBL® home entertainment system with soundbar and wireless subwoofer
• Keyed-Alike™ lock system (single key for all doors and locks)
• MORryde® Safe-T-Rail® grab handle
• Residential king mattress (72 in. x 80 in.) with under-bed storage
• Three 40 lb. LP propane bottles with automatic regulator
• Overlander II Solar Package featuring 30-amp controller, 1,800W inverter, and two 200W solar panels

Luxury Package (Mandatory)

• 2nd electric patio awning
• 40 in. 4K exterior Smart LED TV
• 40 in. 4K Smart LED TV in bedroom
• 6-point hydraulic auto-leveling system
• Central vacuum system with dust port
• Day/night roller shades in living room
• Frameless dark-tinted safety-glass windows
• GE® 21 cu.ft. residential refrigerator with 1,800W inverter
• GE Profile™ Series 30 in. residential convection microwave with built-in air fryer
• GE Profile™ Series 24 in. residential range with 3.7 cu.ft. oven and 9,100 BTU high-output burner
• High-gloss gel-coated sidewalls
• LED fireplace with electric space heater
• MORryde® StepAbove™ Stow & Go steps
• Oversized multi-battery compartment with room for 4–6 batteries
• Powered 50-amp cord reel
• Residential solid-surface kitchen and bathroom countertops
• Residential walk-in shower with teak seat
• Solid hardwood cabinet doors, stiles, and fascia with hand-painted 90° poly sheen finish
• Residential “Do-It-All” sink
• Washer/dryer prep
• Pull-out “Roll Top” dinette with two freestanding chairs and two folding chairs
• Residential NuvoH2O® whole-coach water treatment system with water softening and triple-cartridge filtration
• NuvoH2O® Ultra Filter with medical- and military-grade filtration technology for kitchen faucet and refrigerator ice/water dispenser, conveniently located under sink

5 Star Handling Package (Mandatory)

• 17.5 in. 16-ply tires
• Dexter® axles with ABS and Tow Assist, including Nev-R-Adjust® brakes and E-Z Lube® hubs
• MORryde® LRE4000™ rubberized suspension system
• MORryde® rubber pin box
• Wet-bolt fasteners with bronze bushings and 4,000 lb. leaf springs

Options

• 3rd living area A/C (15,000 BTU)
• 20 cu. ft. 12V refrigerator
• Generator prep
• 7,000W Onan® dual-fuel generator (includes generator prep)
• Dual-pane tinted safety-glass windows
• Slideout awning (3) (36FBTS, 32RLTS, 38FBRK)
• Slideout awning (4) (38SSWS)
• Outside Halo® griddle for JayPort® system (36FBTS, 32RLTS, 38FBRK, 38SSWS)
• 7K axle with hydraulic disc brakes (no ABS) (32RLTS)
• 8K axle with hydraulic disc brakes (no ABS)
• MORryde® independent suspension with 8K axles and disc brakes (N/A with ABS)
• Queen residential foam-top mattress
